The Sony PVM14L5 is a Multiformat color critical monitor for 16:9 and 4:3 aspect ratio.
The Sony PVM14L5 has an add-on slot in the back for a Sony BKM-142HD HD SDI Input Adapter, allowing it to accept a wide range of digital signals:
- Standard Definition 480/60i, 575/50i
- High Definition 1035/60i, 1080/50i, 1080/60i, and 720/60p.
H/V Delay, underscan, Blue Only, MONO, 4:3 Area Marker and three color Tally (Red Green, Amber) functions are provided for optimal display.
Input connectors for analog composite, S-video (Y/C) and RGB/component signals.
Digital Capable (with add-on card):
By adding the digital card, this monitor will handle both your SD and HD images.
On Screen Display
Displays both 16:9 and 4:3
Capable of operating between AC 100 V to 240 V
Utilizes an 800 TV Line CRT using SMPTE C phosphors for consistent and accurate color reproduction.
Displays both 16:9 and 4:3 aspect ratio.
Capable of operating between AC 100 V to 240 V.
Color System: NTSC/PAL
Scanning Frequency: 15.625 kHz to 45 kHz
Color Temperature: D65/D93/User Adjustable
Composite: Loop through BNC, 1.0 Vp-p, negative sync, automatic 75 ohm termination
Y/C: Loop through Mini DIN 4-pin, automatic 75 ohm termination
Parallel Remote: Modular 8-pin (assignable)
Serial Remote: D-sub 9 pin (RS-485)
